Tank Filling Oxygen Generator

Short Description:

Tank Filling Oxygen Generator is more and more accepte by customers. It is safe and simple to operate, can save the trouble of manual bottle replacement. It can be operated at full load for 24 hours with low equipment noise and long service life.Jiangsu Hongbo launched the tank filling oxygen generator which automatically fills bottles with a full set of processes, high oxygen purity, low cost and fast investment recovery.


Product Detail

Product Tags

Bottled oxygen is gradually replaced by the oxygen produced by the oxygen generator due to the trouble of changing bottles and high cost. Jiangsu taioxygen launched the filling and filling oxygen generator, which automatically fills and fills bottles with a full set of processes, with high oxygen purity, low cost and fast investment recovery.

Products Advantages:

  • Provide clean raw air for the oxygen generator through the air purification component, Ensure the adsorption efficiency and service life of molecular sieve;
  • The air storage tank assembly ensures the stable gas consumption of the system;
  • Oxygen buffer tank ensures stable gas supply to the system;
  • International famous brand valves (Burkert, Gumu, Germany) are selected,
    Japan (SMC, CKD, etc.) is a reliable guarantee for the stable operation of PSA equipment;
  • The unique pressing technology is a reliable guarantee for the service life of molecular sieve;
  • The pressing force is constant and does not change with the change of stroke;
  • The cylinder is equipped with indicator rod, which can directly measure the stroke;
  • With sinking alarm and limit shutdown function;
  • The gas required by the cylinder is directly taken from the adsorption tower,
    which can work synchronously with the adsorption tower at any time;
  • Testing process in strict accordance with standards,
    Ensure that each equipment leaving the factory is safe, reliable and stable;







 Model 产气量Gasproduction 氧气浓度Oxygenconcentration  Power 外形尺寸Overalldimension 装瓶压力Bottling  pressure  Weight
F0 93-20 It is equivalent to   filling 4 40L steel   cylinders per hour 93% ± 3% Total power:42.5KWAir compressor:30KWSupercharger :11KW

Other:1.5KW

20foot standard container; 5898mm( long)*2352mm     (wide)*2393mm( high) 130-150bar ≈5.6T
F0 93-25 It is equivalent to   filling 5 40L steel   cylinders per hour 93% ± 3% Total power:49.5KWAir compressor:37KWSupercharger :11KW

Other:1.5KW

20 foot standard container; 5898mm(long)*2352mm(wide)*2393mm(high) 130-150bar ≈5.73T
F0 93-30 It is equivalent to   filling 6 40L steel   cylinders per hour 93% ± 3% Total power:62.1KWAir compressor:45KWSupercharger :15KW

Other:2.1KW

20 foot standard container; 5898mm(long)*2352mm(wide)*2393mm( high) 130-150bar ≈6.0T
F0 93-50

It is equivalent to   filling 10 40L steel cylinders per hour

93% ± 3% Total power:96.6KWAir compressor:75KWSupercharger :18.5KW

Other:3.1KW

40 foot container;12032mm( long)x2352mm (wide)x2698mm( high) 130-150bar ≈10T
F0 93-60

It is equivalent to   filling 12 40L steel cylinders per hour

93% ± 3% Total power:100KWAir compressor:75KWSupercharger:22KW

Other:3.1KW

40 foot container;12032mm( long)x2352mm (wide)x2698mm( high) 130-150bar ≈11T

微信截图_20240730143650
